The DKURVE 4-Way UK Rack PDU provides four UK sockets in a compact 19-inch, 1U horizontal design for server racks and network cabinets. It features a CHINT RCD behind a clear protective cover, a black housing, and mounting brackets for rack installation.
A 2-metre, 3G 1.5mm² cable with a UK three-pin plug provides the power input. Internal copper busbars distribute power across the four sockets. The PDU is rated at 13A, 250V AC and up to 3250W.
Key features
Four UK sockets
CHINT RCD with 30mA earth-leakage protection
19-inch, 1U horizontal rack mounting
2-metre, 3G 1.5mm² cable with UK plug
Internal copper busbar connections
Mounting fittings included
Technical specifications
PDU rating: 13A, 250V AC, 50/60Hz
Maximum power: 3250W
RCD model: CHINT NXBLE-63YH
RCD breaker rating: 16A, Type C
RCD residual-current trip rating: 30mA
Dimensions: 483 × 45 × 44.8 mm
Colour: Black
The 16A figure is the RCD breaker rating. The complete PDU is rated at a maximum of 13A.
